NEW QUESTION # 92
Which statement is true concerning cookie persistence.
- A. Cookie persistence allows persistence even if the data are encrypted from client to pool member.
- B. If a client's browser accepts cookies, cookie persistence will always cause a cookie to be written to the client's file system.
- C. Cookie persistence uses a cookie that stores the virtual server, pool name, and member IP address in clear text.
- D. Cookie persistence allows persistence independent of IP addresses.
Answer: D
NEW QUESTION # 93
Which statement accurately describes the difference between two loadElbalancing modes specified as "member" and "node".
- A. There is no difference; the two terms are referenced for backward compatibility purposes.
- B. When the loadElbalancing choice references "node", priority group activation is unavailable.
- C. LoadElbalancing options referencing "nodes" are available only when the pool members are defined for the "any" port.
- D. When the loadElb alancing choice references "node", the addresses' parameters are used to make the loadElbalancing choice rather than the member's parameters.
Answer: D
NEW QUESTION # 94
Where is persistence mirroring configured.
- A. It is always enabled.
- B. It is part of a pool definition.
- C. It is part of a virtual server definition.
- D. It is part of a profile definition.
Answer: D
NEW QUESTION # 95
Which Virtual Server type prevents the use of a default pool?
- A. Performance HTTP
- B. Standard
- C. Performance (Layer 4)
- D. Forwarding (IP)
Answer: D
Explanation:
Forwarding (IP) cannot be associated with the pool.
NEW QUESTION # 96
A BIGElIP has a virtual server at 150.150.10.10:80 with SNAT automap configured. This BIGElIP also has a SNAT at 150.150.10.11 set for a source address range of 200.200.1.0 / 255.255.255.0. All other settings are at their default states. If a client with the IP address 200.200.1.1 sends a request to the virtual server, what is the source IP address when the associated packet is sent to the pool member.
- A. 200.200.1.1
- B. Floating self IP address on VLAN where the packet leaves the system
- C. 150.150.10.11
- D. Floating self IP address on VLAN where the packet arrives on the system
Answer: B
NEW QUESTION # 97
A BIG-IP Administrator needs to check the memory utilization on a BIG-IP system. Which two methods can the UIG IP Administrator use? (Choose two.)
- A. Run the tmsh show/sys traffic command
- B. Go to Statistics > Module Statistics > Memory in the configuration utility
- C. Go to Statistics > Module Statistics > Traffic Summary in the configuration utility
- D. Run the tmsh show/sys memory command
- E. Go to System > Disk Management in the configuration utility
Answer: B,D
NEW QUESTION # 98
Which IP address will the client address be changed to when SNAT automap is specified within a Virtual Server configuration.
- A. It will alternate between the floating and noEl nfloating self IP address on the VLAN where the packet leaves the system so that port exhaustion is avoided.
- B. It will alternate between the floating and noElfnloating self IP address on the VLAN where the packet arrives on the system so that port exhaustion is avoided.
- C. The floating self IP address on the VLAN where the packet arrives on the system.
- D. The floating self IP address on the VLAN where the packet leaves the system.
Answer: D
NEW QUESTION # 99
The current status of a given pool member is nknown. Which condition could explain that state. The current status of a given pool member is .nknown. Which condition could explain that state.
- A. The member has a monitor assigned to it and the most recent monitor was successful.
- B. The member has a monitor assigned to it and the monitor did not succeed during the most recent timeout period.
- C. The member has no monitor assigned to it.
- D. The member's node has a monitor assigned to it and the monitor did not succeed during the most recent timeout period.
Answer: C
NEW QUESTION # 100
A BIG-IP Administrator needs to determine which pool members in a pool have been manually forced offline and are NOT accepting any new traffic. Which status icon indicates this?
A)
B)
C)
D)
- A. Option
- B. Option
- C. Option
- D. Option
Answer: B
NEW QUESTION # 101
How is MAC masquerading configured?
- A. Specify the desired MAC address for each floating selfIP address for which you want this feature enabled.
- B. Specify the desired MAC address for each VLAN on the active system and synchronize the systems.
- C. Specify the desired MAC address for each VLAN for which you want this feature enabled.
- D. Specify the desired MAC address for each selfIP address for which you want this feature enabled.
Answer: C
NEW QUESTION # 102
Generally speaking, should the monitor templates be used as production monitors or should they be customized prior to use.
- A. While some templates, such as ftp, must be customized, those that can be used without modification are not improved by specific changes.
- B. Monitor template customization is only a matter of preference, not an issue of effectiveness or performance.
- C. Most templates, such as https, should have the receive rule customized to make the monitor more robust.
- D. Most templates, such as http and tcp, are as effective as customized monitors.
Answer: C
NEW QUESTION # 103
How is persistence configured?
- A. Persistence is a profile type; an appropriate profile is created and associated with virtual server.
- B. Persistence is an option for each pool member. When a pool is defined, each member's definition includes the option for persistence.
- C. Persistence is a global setting; once enabled, loadbalancing choices are superceded by the persistence method that is specified.
- D. Persistence is an option within each pool's definition.
Answer: A
NEW QUESTION # 104
When can a single virtual server be associated with multiple profiles?
- A. Unlimited. Profiles can work together in any combination to ensure that all traffic types are supported in a given virtual server.
- B. Rarely. One combination, using both the TCP and HTTP profile does occur, but it is the exception.
- C. Never. Each virtual server has a maximum of one profile.
- D. Often. Profiles work on different layers and combining profiles is common.
Answer: D
NEW QUESTION # 105
Some users who connect to a busy Virtual Server have connections reset by the BIG-IP system. Pool member resources are NOT a factor in this behavior. What is a possible cause for this behavior?
- A. The Rewrite Profile has NOT been configured.
- B. The Connection Limit is set too low.
- C. The Connection Rate Limit is set too high
- D. The server SSL Profile has NOT been reconfigured.
Answer: B
Explanation:
The topic explains that the connection reset behavior is caused by the vs configuration rather than the server resource problem. The answers B C are all configuration at the service forwarding level. If there is a problem with the configuration, it is all a problem rather than some users. Answer C's Connection Limit will cause a reset behavior when the connection reaches the threshold.
NEW QUESTION # 106
Which is an advantage of terminating SSL communication at the BIGIP rather than the ultimate web server?
- A. Terminating SSL at the BIG-IP eliminates the need to use SSL acceleration hardware anywhere in the network.
- B. Terminating SSL at IP the eliminates BIG all unencrypted traffic from the internal network.
- C. Terminating SSL at the BIG-IP eliminates the need to purchase SSL certificates from a certificate authority.
- D. Terminating SSL at the BIG-IP can eliminate SSL processing at the web servers.
Answer: D
NEW QUESTION # 107
A BIG-IP Administrator is creating a new Trunk on the BIG-IP device. What objects should be added to the new Trunk being created?
- A. Network routes
- B. Interfaces
- C. VLANS
- D. IP addresses
Answer: B
Explanation:
Explanation
trunk is a portchannel, you need to add a physical interface.
NEW QUESTION # 108
A BIG-IP Administrator needs to purchase new licenses for a BIG-IP appliance.
The administrator needs to know if a module is licensed and the memory requirement for that module.
Where should the administrator view this information in the System menu?
- A. Configuration > Device
- B. Resource Provisioning
- C. Configuration >OVSDB
- D. Software Management
Answer: B
NEW QUESTION # 109
A web server administrator informs the BIG-IP Administrator that web servers are overloaded Starting next month, the BIG-IP device will terminate SSL to reduce web server load. The BIG-IP device is ready using client SSL client profile and Rules on HTTP level. What actions should the BIG-IP Administrators to achieve the desired configuration?
- A. Remove the chart SSL profile and change the Virtual Server to accept HTTP
- B. Remove the server SSL profile and change the Virtual Server to accept HTTP traffic
- C. Remove the client SSL profile and configure the Pool Members to US HTTP
- D. Remove the server SSL profile and configure the Pool Members to use HTTP
Answer: D
NEW QUESTION # 110
When using the setup utility to configure a redundant pair, you are asked to provide a "Failover Peer IP". Which address is this.
- A. an address on the current
system used to
initiate mirroring
and network failElover heartbeat messages - B. an address on the current system used to listen for failElover messages from the partner BIGIP
- C. an address of the other system in a redundant pair configuration
- D. an address of the other system in its management network
Answer: C
NEW QUESTION # 111
A development team needs to apply a software fix and troubleshoot one of its servers. The BIG-IP Administrator needs to immediately remove all connections from the BIG-IP system to the back end server. The BIG-IP Administrator checks the Virtual Server configuration and finds that a persistence profile is assigned to it. What should the 8IG-IP Administrator do to meet this requirement?
- A. Set the pool member to a Forced Offline state.
- B. Set the pool member to a Disabled state and manually delete existing connections through the command line.
- C. Set the pool member to a Forced Offline state and manually delete easting connections through the command line.
- D. Set the pool member to a Disabled state.
Answer: C
NEW QUESTION # 112
A standard virtual server is defined with a pool and a SNAT using automap. All other settings for the virtual server are at defaults. When client traffic is processed by the BIG-IP, what will occur to the IP addresses?
- A. Traffic initiated to the virtual server will have the destination address translated to a pool member address and the source address translated to a self-IP address. Traffic arriving destined to other destinations will have the source translated to a self-IP address only.
- B. Traffic initiated to the virtual server will have the destination address translated to a pool member address and the source address translated to a self-IP address.
- C. Traffic initiated by selected clients, based on their IP address, will have the source address translated to a self-IP address but the destination will only be translated if the traffic is destined to the virtual server.
- D. Traffic initiated by the pool members will have the source address translated to a self-IP address but the destination address will not be changed.
Answer: B
NEW QUESTION # 113
Refer to the exhibit.
An organization is reporting slow performance accessing their Intranet website, hosted in a public cloud. All employees use a single Proxy Server with the public IP of 104.219.110.168 to connect to the Internet. What should the BIG-IP Administrator of the Intranet website do to fix this issue?
- A. Change Source Address to 104.219.110.168/32
- B. Change Load Balancing Method to Least Connection
- C. Change Fallback Persistence Profile to source_addr
- D. Change Default Persistence Profile to cookie
Answer: D
NEW QUESTION # 114
......
